    740-800HV tungsten steel Electrical Glove Testing Machine , Durability Testing Machine AC220V(GW-099)

    Ask Lasest Price
    Brand Name : Great Win
    Model Number : GW-099
    Certification : CE CNAS
    Price : USD1200-3850/Set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500 sets/year
    Delivery Time : 20 work days
    • Product Details
    • Company Profile

    740-800HV tungsten steel Electrical Glove Testing Machine , Durability Testing Machine AC220V(GW-099)

    740-800HV tungsten steel Electrical Glove Testing Machine , Durability Testing Machine AC220V(GW-099)

    Brief introduction:
    This tester is use to determine the protective capability of the safety glove against cutting.But,it is not available for safety glove made by hard material.A driving rotation found blade under a specified load cuts the glove held by the fixture of tester to and fro. After test ,compare it with its original statuses to get the results.

    Technical Specifications:

    horizontal motion stroke
    50mm
    load on the blade
    5±0.05N
    The blade cutting speed
    10cm/ s linear speed
    The thickness of the blade
    3±0.3mm
    The angle of the cutting
    30°-35°
    The hardness of the blade
    740-800HV tungsten steel
    Sampling
    5 sets, (blade direction of rotation and movement in the opposite direction)
    Counter
    LED display 0~999
    Volume
    60*20*45cm
    Weight
    59KG
    Power
    1∮,AC220V,2A


    •Standard for:
    GB/T20991-2007 5.5,ISO EN 20344:2004.
